Introduce poetry to your Kube config with ksonnet

October 15th, 2018

Returning to the 101 ways to create Kubernetes configuration theme, next up is ksonnet from the folks at Heptio. (I have no doubt that there are 101 ways to create Kubernetes configuration but I’m afraid I don’t really intend to cover all of them on this blog!) ksonnet has a different take yet again from Helm and kustomize. In many ways, it is more powerful than either of them but that power comes at the cost of a fairly steep learning curve.

The name is derived from Jsonnet, a data templating language that came out of Google back in 2014. Jsonnet essentially extends JSON with a scripting syntax that supports the definition of programming constructs such as variables, functions, and objects. The ‘Aha!’ moment for me with ksonnet was in realizing that it could be used as a simple template structure in much the same way as Helm. You start with some Kubernetes configuration in JSON format (and yq is your friend if you need to convert from YAML to JSON first) and from there you can extract parameters. I say ‘it could’ because you’d typically only take this approach if you were actually converting existing configuration but realizing this helped me get beyond some of the slightly strange syntax you see in generated files.

As usual, Homebrew is your starting point: brew install ksonnet/tap/ks. ksonnet has an understanding of the different environments to which an application is deployed and, when you issue ks init myapp, it takes the cluster that your current kube config is pointing at as the default environment (although you can override this with --context).

ksonnet then has the concept of ‘prototypes’ which are templates for generating particular types of application component when supplied with suitable parameters. These are provided by ‘packages’ which, in turn, come from a ‘registry’ stored on GitHub. Stealing from the tutorial, we can generate code for a simple deployment and service with the deployed-service prototype giving the image name and service type as parameters e.g.

At this point, we can use ks show default to return the YAML that would be generated or ks show apply to actually apply it to the default environment. I highly recommend doing the tutorial first and not the web-based tour as it shows you that you can get a long way with ksonnet without actually editing, or even looking at, any of the generated files. For example, you can use ks env add to create another environment and then ks param set to override the values of parameters for a particular environment as you might with Helm or kustomize.

Of course, the real power comes when you drop into the code and make use of ksonnet features like parts and modules to enable greater reuse of configuration in your application. At that point though, you really should take the time to learn jsonnet properly!

British Schools Score Champions

October 13th, 2018

Today we were down at the British Schools Orienteering Association Score Champs, taking place at Moors Valley Country Park. It was a lovely day to be out in the forest (particularly compared with Friday’s weather). This was the first score event that Emma and Duncan have done on their own and the game plan was simply for them to head around the loop of white-standard controls, picking up a few others on their way. They both executed on this and, despite (or perhaps because) of being back well inside the 45-minute time limit, won their respective courses. (Duncan ran up as the event starts at Year 5.) Prizes were presented by Gillian Cross, author of the Demon Headmaster series, and member of the organising club. Results and more pictures can be seen on the British Schools Orienteering Association website. We won’t be travelling up to the non-score Champs in Blackburn later this year but nearby BADO are due to host the event in 2019…

kail: kubernetes tail

October 12th, 2018

A short post for today but it relates to a tool that every Kubernetes user should have in their toolbox: kail. Although most users probably know that kubectl logs will, by default, show the logs for all containers in a pod and that it has --tail and -f options, fewer probably know that is has a -l option to select pods based on label. Kail takes tailing Kubernetes logs to a whole new level.

For Homebrew users, it’s available via brew install boz/repo/kail. When executed without any arguments it tails logs for all containers in the cluster which is probably not what you want unless your cluster is very quiet! There are, however, flags to let you filter not just on pod, container, and label, but also namespace, deployment, replica set, ingress, service, or node. Flags of the same type are ORed together, different flags are ANDed. And that’s pretty much all there is to it but anyone who finds themselves watching the logs of any moderately complex application will wonder how they lived without it!

Kustomizing Kubernetes Konfiguration

October 11th, 2018

Finally, I get to write that blog post on kustomize! kustomize is yet another tool attempting to solve the problem of how to make Kubernetes configuration re-usable. Unlike, say, Helm, kustomize allows configuration to be overridden at consumption time without necessarily having allowed for it when the configuration was originally produced. This is great if you are attempting to re-use someone else’s configuration. On the flip-side, you might prefer to use something like Helm if you actually want to limit the points of variability e.g. to ensure standardization across environments or applications.

You know the drill by now: the go binary CLI can be obtained via brew install kustomize. There is one main command and that is kustomize build. That expects to be pointed at a directory or URL containing a kustomization.yaml file. Running the command outputs the required Kubernetes resources to standard output where they can then be piped to kubectl if desired.

The kustomization.yaml can contain the following directives:

  • namespace – to add a namespace to all the output resources
  • namePrefix – to add a prefix to all the resource names
  • commonLabels – to add a set of labels to all resources (and selectors)
  • commonAnnotations – to add a set of annotations to all resources
  • resources – an explicit list of YAML files to be customized
  • configMapGenerator – to construct ConfigMaps on the fly
  • secretGenerator – to construct Secrets via arbitrary commands
  • patches – YAML files containing partial resource definitions to be overlayed on resources with matching names
  • patchesJson6902 – applies a JSON patch that can add or remove values
  • crds – lists YAML files defining CRDs (so that, if their names are updated, resources using them are also updated)
  • vars – used to define variables that reference resource/files for replacement in places that kustomize doesn’t handle automatically
  • imageTags – updates the tag for images matching a given name

That’s a pretty comprehensive toolbox for manipulating configuration. The only directive I didn’t mention was bases with which you can build a hierarchy of customizations. The prototypical example given is of a base configuration with different customizations for each deployment environment. Note that you can have multiple bases, so aws-east-staging might extend both aws-east and staging.

One of the refreshing things about kustomize is that it explicitly calls out a set of features that it doesn’t intend to implement. This introduces the only other command that the CLI supports: kustomize edit. Given that one of the stated restrictions is that kustomize does not provide any mechanism for parameterising individual builds, the intent of this command is to allow you to script modifications to your kustomization.yaml prior to calling build.

It’s worth noting that kustomize can be used in combination with Helm. For example, you could run helm template and then use kustomize to make additional modifications that are not supported by the original chart. You can also use them in the reverse order. The Helmfile docs describe how to use Helmfile’s hooks to drive a script that will use kustomize to construct the required YAML, but then wrap it in a shell chart so that you get the benefit of Helm’s releases.

Birthday Hash

October 8th, 2018

Lest this blog become entirely about technology: it was Duncan’s 9th birthday last week. His party took place the weekend before and, given it was up at Farley Mount and all outdoors, the weather was very kind to us. Emma and I laid out a hash whilst Christine and Duncan waited for ‘the boys’ to arrive. We returned to find a game of capture the flag (a Cub favourite) well underway.

Having laid the hash was a good excuse to stay behind and mind the lunch whilst everyone else disappeared off into the woods. Thankfully they all returned again about half an hour later although I could still hear them for about half that time! In the meantime, I’d started frying for the bacon sarnies. I was cooking on gas but the plan was to light a fire in the site’s barbecue grill so that they could toast marshmallows for s’mores. Christine had even bought a flint and steel and, with copious quantities of cotton wool, they did eventually get a fire going. This was quite something given the trouble I then had just trying to light the candles on the cake (with a match I hasten to add). Christine had lots of other activities planned but they seemed happy to round things off with another game of capture the flag.

When the day itself came it was fairly uneventful. Emma gets lots of enjoyment from just watching other people open presents and, given she leaves for school before Duncan gets out of bed these days, he was kind enough to wait until they’d both got back from school. Duncan had a week off football so that things weren’t quite as manic as usual but, after a birthday tea (where, as you can see, he only got the leftovers of his cake from the party!) he and Christine then headed out to Cubs as usual.

Helmfile and friends

October 8th, 2018

Having written a post on Helm, I feel obliged to follow it up with one on Helmfile, a project that addresses some of the issues that I identified with deploying multiple Helm charts. In particular, it provides an alternative approach to the umbrella chart mechanism that Jenkins X uses for deploying the set of charts that represent an environment.

Yet again, we have a go binary, available via brew install helmfile. At its most basic, we then have a helmfile.yaml that specifies a set of releases with a name, chart, namespace and override values for each. A helmfile sync will then perform an install/upgrade for all the releases defined in the file. One thing I failed to mention in my Helm post was that Helm supports plugins on the client side. One such plugin is the helm-diff plugin which, as you’d probably guess from the name, gives you a diff between the current state of a release and what it would look like after an upgrade or rollback. The plugin is installed with:

With this in place, we can now use helmfile diff to see the changes that would take place across all of our releases. The helmfile apply command combines this with a sync to conditionally perform an upgrade only if there are differences. There is a set of other helmfile commands that all perform aggregate operations across all the releases: delete, template, lint, status and test.

So far so good but nothing that couldn’t be achieved with a pretty short bash script. Where things get more interesting is that the helmfile.yaml is actually a template in the same way as the templates in a Helm chart. This means we can start to do more interesting things like defining values in one place and then reusing them across multiple releases. Helmfile has the explicit concept of an environment, passed in as a parameter on the CLI. We can use a single YAML file and use templating to have different values apply in each environment or, in the extreme, only deploy charts in some environments.

Helmfile also has some tricks up its sleeve when it comes to secrets. Most trivially, if your CI allows you to configure secrets via environment variables you can consume these directly in the helmfile.yaml. You can also store secrets in version control encrypted in a YAML file and then have another Helm plugin, helm-secrets, decrypt them with PGP or AWS KMS.

Helmfile has some features to help you as the size of your deployment grows. You can, for example, specify a selector on commands to only apply them to matching releases. This can be helpful if deploying all the changes at once is likely to create too much churn in your cluster. You can also split the file into multiple files in one directory (executed in lexical order) or over multiple directories (accessed via a glob syntax).

For anything else, there are prepare and cleanup hooks to allow you to execute arbitrary commands before and after deployment. Oh, and if you’re using a containerized deployment pipeline, it’s available packaged up in an image, ready for use. Finally, if you don’t take to Helmfile, take a look at Helmsman instead.

Helm: the Package Manager for Kubernetes

October 5th, 2018

I wanted to take a look at ksonnet and kustomize  but felt I should write about what I know best first, and that’s Helm. All three tools are trying to tackle the same basic problem: enabling the re-use of Kubernetes configuration where typically we want some level of customisation each time we use the configuration, whether that’s to reflect the latest deployment or the environment we’re deploying to.

The starting point for Helm is a client binary called, unsurprisingly, helm, and is available from brew as kubernetes-helm. The current version of Helm also has a server-side component called Tiller and that is deployed by executing helm init --wait (the wait flag indicates to wait until the Tiller pod has started before returning). Note that Helm is pretty picky about having matching versions of client and server.

In keeping with Kubernetes nautical theme, Helm’s unit of packaging is the chart. A new chart called test can be easily constructed with the command helm create test. This results in a directory called test with the following contents:

Chart.yaml contains some basic meta-data about the chart such as name, description and version. Note that Helm draws a distinction between the version of the chart and the version of the application that the chart deploys. We’ll come back to the empty charts directory later. The templates directory contains the YAML files that we’d expect to find for a basic Kubernetes application and these can be extended and/or replaced as needed. As the directory name suggests though, and this is the key to reuse, the files are actually templates. If we look in deployment.yaml we’ll see the mustache syntax used to support substitution:

We can see that it’s going to use the name from the Chart.yaml for the container name. The default contents for the Values fields are taken from values.yaml and typically this also contains comments describing the intent of each value. The templates use Go template syntax and support the sprig functions along with a few Helm-specific extensions. The syntax is pretty rich and supports pretty much any manipulation you’re likely to want to perform on configuration. The _helpers.tpl file defines some helper functions that are used throughout the chart. Finally, the NOTES.txt contains text that is output when the chart is installed, typically providing usage instructions for the installed application. This file also supports templating.

The default generated chart deploys a pod with nginx in it. If we look in values.yaml we can see that, by default, it’s going to use the stable image tag. We can override this at install time. For example:

If we want to override lots of values then we can specify then via a YAML file instead. Indeed, we can specify multiple files so there might, for example, be one for production and another for us-east-1. The name here is optional but, at least for scripting, it’s easier not to use one of the generated names. Note that, although the release is deployed to a namespace (and Helm isn’t capable of tracking resources that explicitly target some other namespace), the name is scoped to the tiller instance (i.e. the cluster if you only have one tiller install).

There are others commands for operating on releases: delete, upgrade, rollback, list, status and get, all of which do pretty much what you’d expect of them. As the upgrade, rollback and history commands suggest, helm is tracking revisions of a release. Tip: if you’re in some CD pipeline and you don’t know whether you’re upgrading or installing for the first time, use helm upgrade --install and it will do the right thing. Something else to watch out for is the --wait option on an upgrade. This waits until you have at least replicas - maxUnavailable pods available. Given that these are both typically one by default, don’t be surprised when it doesn’t appear to be waiting!

We’ve just installed a chart off the local filesystem but, as with any decent package manager, Helm has the concept of a repository. By default, the helm CLI is configured with the stable and incubator repositories. You can search these with helm search or head over to Kubeapps for a shiny catalog. These show the real power of Helm when, with a simple helm install stable/wordpress, you can re-use someone else’s hard work in defining the best practise for deploying WordPress on Kubernetes. You can add other repositories (e.g. that for Jenkins X) and you can create your own, either via a simple file server or, a read-write repository using ChartMuseum and the Monocular UI.

The packages themselves are simply .tgz files although the helm package command also supports things like signing the package. I said I’d come back to the charts directory and the WordPress chart is a good example of how this can be used. The WordPress chart actually also deploys the MariaDB chart to provide persistent storage. This is achieved by placing a requirements.yaml in the root of the chart that specifies the dependency. Dependencies can be fetched with helm dependency update or resolved at packaging time with the --dependency-update flag.

Jenkins X makes use of this sub-chart capability in the way it deploys environments. The repo for each environment contains a Helm chart which specifies as dependencies all of the application charts to deploy in to the environment. One downside of this approach is that you then only see a Helm release for the entire environment. Another issue with sub-charts relates to the way their values are overridden. The values for a sub-chart can be overridden by prefixing with the name or alias given in requirements.yaml but there is no good way to get the same value in to multiple sub-charts. If you have control over the sub-charts you can write them to retrieve values from a global scope but that doesn’t help if you’re trying to re-use someone else’s efforts.

Helm provides lots of other goodness. You can annotate resources with hooks so that they are run pre or post install, upgrade, rollback or delete. There is even a crd-install annotation to ensure that your CRDs are created before other resources attempt to use them. You should also know helm lint and helm test. The latter executes resources in the chart with the test-success or test-failure hook annotations. You can use these to provide a detailed check of whether a release was successfully deployed.

An overview of Helm wouldn’t be complete without a reference to Helm v3. At the beginning I indicated that the current version deploys a server-side component. That is particularly problematic when it comes to security as, even if you enable mutual-TLS, any user that can connect can perform any action supported by the service account under which Tiller is running, losing you all of Kubernetes’ RBAC benefits. You can mitigate the problem by installing a Tiller per namespace but you’re still left managing certificates. IBM Cloud Private implemented their own Tiller to do identity assertion in order to overcome this problem. Jenkins X now supports using helm template to render charts client-side before deploying with kubectl. This means that you don’t get any of the Helm release management but then that is handled by Jenkins X anyway. Helm 3 promises to do away with Tiller but still share release information server-side via CRDs. Sadly as James alludes to in his blog post, there’s not a lot of public progress being made on Helm 3 at the moment.

Continuous Development with Skaffold

October 4th, 2018

Next on the list of projects utilised by Jenkins X (and this is a theme that could run and run) is Google’s Skaffold. There is an intersection between the capabilities of Skaffold and Draft. Skaffold does not provide anything like packs (this is where Jenkins X uses Draft) so you need to provide your own Dockerfile and Kubernetes configuration (raw YAML, kustomize templates, and Helm charts are supported). Both projects, however, aim to simplify the process of building an image and deploying it to a Kubernetes cluster to speed iterative development of applications that have hard dependencies on a Kubernetes environment, or the services running therein.

In the Skaffold case, a skaffold run will do a one-time build and deploy and a skaffold dev will continuously monitor the filesystem to determine when to rebuild and update. As previously discussed, the value of being able to do this versus needing a smart incremental deployment from an IDE is very much dependent on how quick that rebuild process is for your application language/runtime of choice. As with Draft, it has the ability to allow you to skip pushing to a registry when you’re working with a local cluster.

So what does Skaffold offer that Draft doesn’t? Principally, that it is not designed to be used solely at development time. The idea is that the same skaffold run may also be used as part of your continuous deployment pipeline. If you’re a GCP user, this extends to capabilities like using Google Cloud Builder or Kaniko rather than a simple Docker build and, of course, interaction with a registry.

As this annotated skaffold.yaml shows, it has a few other neat tricks. You have lots of flexibility over the tagging scheme used for images: SHA, git commit ID, timestamp, or a Golang template. For a Docker build, you can specify build arguments and cache images. You can even configure a bazel build instead of a Docker build.

One thing to watch is that you adhere to the convention used for substituting the names of the built images. When using Helm, for example, the default behaviour is to pass the combination of image repository/name and tag as a single value. If you chart is using the default Helm convention of separate .repository and .tag values then you need to specify a different imageStrategy. If your chart expects a three-way split between repository, name, and tag, then you’re on your own!
